KX-192-100 is a High-Voltage LiFePO4 system for energy storage, which contains three main parts :

(4 * Standard 5U module cases (48V100AH battery pack for each)

(1* Standard cabinet

(1* HV Box with battery ...

This type of power system is a backup power system with a battery management system, which captures and controls information about the battery, including temperature, voltage, charge current, and discharge current.

Through series-parallel connections of a number of cells with the associated management system, the lithium iron phosphate battery module is the eco-friendly power system with a rated capacity of 100Ah and a nominal voltage of 192V.

This power system uses quality cells and is manufactured using advanced production technology, so it has features such as extended battery life, high specific energy, low internal resistance, excellent large current discharge performance, and wide operating temperature range, and is safe and reliable.
