Welcome to Koxin Energy Limited
An energy storage system based on lithium-ion batteries provides a high value, efficient, robust, long-lasting, and reliable solution for commercial and industrial applications.
Send Inquiry
· 380V+220V AC Output
· Ac Dc Input Auto Switch
· Foldable Solar Panel
· Remote-control & Security Lock
LiFePO4 Battery Cabinets offer the capacity of scaling from 10 kWh to 50 kWh by simply adding additional battery modules.
It is a cabinet specifically designed by Koxin for the needs of marine energy storage in the market.
The outer cabinet is galvanized steel, epoxy-sprayed on the surface, which supports anti-ultraviolet, anti-aging, rain, dust, and so on.
Installation; 19-inch back rack inside the cabinet, equipped with power distribution devices such as temperature control unit, lightning protection, air switch, modular socket, extension board, grounding copper bar, etc.
| Specification | KX 48-250-3KW | |
| DC Input | Rated voltage | 48VDC |
| Number of Module | 5 | |
| Type of Battery | 48V50AH LiFePO4 Module | |
| AC Input | Phase | Three Phase |
| Frequency | 50Hz ±5% | |
| Voltage Range | 380VAC ±15% | |
| Rated Voltage | 380VAC ±2% | |
| Frequency | 50Hz ±1% | |
| Wave Distortion | ≤5% | |
| Dynamic Response | 5% | |
| Crest Factor(CF) | 3.01 | |
| Power Factor | 0.8 | |
| Inverter Efficiency | 87% | |
| HMI | LCD(Touch Screen optional) | |
| Conversion Time | oms online,4ms interactive,EPS 1s | |
| Noise | ≤55db | |
| Dielectric Strength | 1500VAC.1min (input and output) | |
| Cooling Method | Air cooling | |
