8S 15A Smart BMS with Bluetooth and Self-Diagnosis

For battery pack assemblers and OEM engineering teams evaluating 8S 15A Smart BMS with Bluetooth and Self-Diagnosis. Review the configuration and integration requirements before placing a sample order.

View specifications · Check compatibility

Discuss this configuration on WhatsApp

· · ·

Ask about this product on WhatsApp

Product details

Before selecting this BMS

For battery pack assemblers and OEM engineering teams evaluating 8S 15A Smart BMS with Bluetooth and Self-Diagnosis. Review the configuration and integration requirements before placing a sample order.

Chemistry and series count
Confirm the ordered chemistry, series configuration and protection thresholds. Where the table has multiple chemistry columns, specify which configuration you need.
Current and thermal conditions
Send continuous current, peak current with duration, charging current and enclosure cooling conditions. Confirm the board rating for the intended assembly.
Wiring and recovery
Request the connection diagram, port arrangement, connector pinout and protection recovery procedure for the exact board revision.
Host communication
Request the protocol document, pin definitions and firmware revision. Match the host messages and supported functions before approving the sample.

Product specification details

ltem PCM-L08S12-306
Max continious current 15A
Internal resistance ≤30mΩ
Overcharge protection voltage 3.90±0.1V
Overcharge protection delay time 0.5-2S
Overcharge recovery voltage 3.8±0.1V
Overdischarge protection voltage 2.00±0.1V
Overdischarge protection delay time 10-200mS
Overdischarge recovery voltage 2.50±0.1V
Overcurrent protection 65±10A
Short circuit protection YES
Recovery state Disconnect load
Balancing Function YES
Dimension 120*35*9mm
Customize YES
With NTC Optional

Questions before ordering

Will the communication interface work with my controller?

The interface name alone does not establish compatibility. Provide your controller details and required messages, and request the protocol and a sample integration check.

What should I send for a quotation?

Send chemistry, series count, continuous and peak current, charge current, protection settings, board dimensions, communication requirements and sample and production quantities. Confirm hardware and firmware revisions for repeat orders.

Which documents should I request?

Request the exact configuration specification, mechanical drawing and wiring information. State the destination and required compliance documents. Available reports must match the ordered product; this page does not establish certification coverage.

Compare options and prepare your inquiry

These are other configurations to compare, not confirmed substitutes.

BMS selection guide

Need a different configuration?

Share your application, required quantity and operating conditions. Include any dimensions, current limits, communication requirements or documents needed for evaluation.
